Space-Saving All-in-One Solution for Secure & Automated Cash Payments
Banknote & Coin Integrated Recycler — CCS-30 Series

Uninterrupted Reliability

Effortless Automation

Reduce Costs


产品

CCS-30 Series

Compact and Reliable Banknote & Coin Integrated Recycler
Product Overview

The CCS-30 Series is a compact, all-in-one cash recycling system that handles banknote and coin acceptance, validation, counting, storage, and dispensing — all in one unit.


Designed for automated payment environments, its modular design allows easy integration into self-service kiosks, counters, or terminals, making it ideal for retail, transportation, and other self-service applications.


With secure, reliable, and low-maintenance performance, the CCS-30 helps businesses simplify cash handling, boost efficiency, and enhance user experience — all in a small footprint.


Key Benefits

Product Features

Banknote Recycler - CCS-30-B Series
Advanced Counterfeit Detection:Multi-spectrum scanning and magnetic signal recognition ensure high-accuracy validation and secure transactions.
High-Speed Processing:Handles up to 3 notes/second for both accepting and dispensing—enabling fast, smooth transactions.
Large-Capacity Storage:Supports recycling up to 4 denominations, up to 400 notes in total (4 drums x 100 notes). Accepts and dispenses up to 30 bundles per type — allowing flexible change strategies.
Smart Alignment & Sorting:Automatically corrects note orientation and routes unfit notes to a designated cassette — reducing jams and maintenance needs.
CCoin Integrated Recycler
Coin Recycler - CCS-30-C Series
Multi-Dimensional Authentication:Precisely detects counterfeit coins using material, diameter, and thickness analysis.
Fast Coin Handling:Processes up to 5 coins/second, supports up to 50 coins in bulk outlet and inlet — ensuring efficiency in high-volume environments.
High-Capacity Design:Supports recycling up to 8 denominations, up to 3200 coins in total (8 hoppers x 400 coins, RMB 50 cents) — ideal for extended operation with minimal replenishment.
Smart Clearing & Error Prevention:Features include foreign object ejection, residual coin recovery, and automatic overflow transfer — enhancing reliability and user experience.

Technical Specifications

产品
Specification
CCS-30B-40 (banknote recycler)
CCS-30C-80 (coin recycler)
Cash inlet capacity
30 notes in bundle
50 coins
Cash outlet capacity
30 notes in bundle
50 coins
Receiving speed
3.5 notes/second
5 coins/second
Change speed
3.5 notes/second
5 coins/second
Escrow capacity
100 notes
/
Number of recycle box
4 boxes
8 boxes
Recycling box capacity
100 notes/recycle box (400 notes in total for 4 boxes)
400 coins/hopper (3200 coins in total for 8 boxes)
Deposit box capacity
700 notes
2000 coins
Dimension
190 x 450 x 780 mm
190 x 450 x 780 mm
Approval
CE, FCC
CE, FCC
